Accu-Force
Standard III
Spring Smasher
Pro Level Accuracy At Mid Level Price
-
Guaranteed Accuracy & Repeatability to +/- .1%!
-
Optional Spring Unloader - Eliminates Steps & Saves Time
-
Electric Cylinder
-
Manual Toggle Switch Actuation
The Accu-Force STD-III Control
-
5" Color Touchscreen
-
Simple Double Tap to Zero Load or Travel
-
Repeats to +/- .002”!
-
Displays Shock Center to Center and Travel
-
Fast, Accurate & Simple!
-
Push & Pull Modes
Trust Accu-Force to:
-
Measure Spring Loads
-
Unload and Swap Springs Without Changing Ride Height.
-
Rate Coil-Over Shocks & Springs
-
Rate Pull Bars & Trading Arms
-
Rate & Graph Springs
-
Test Rod Ends
Accu-Force GEN 3
Specifications
Size With Wheels (LxWxH) | 15" x 19" x 71" |
Size With Wheels (LxWxH) | 15" x 15" x 71" |
Weight | 125 lbs |
Speed | .25'/sec |
Stroke | 18" |
Power | 110v |
Eye to Eye Travel Range | 28.187" to 10.5" |
Max Spring Unload Height | 27" |
Manual or Automatic | Manual |
Warranty | 12 Month Mfg Defect |
ACCU-FORCE ACCESSORIES
SPRING SMASHER New Billet Pins
AF1812
$30.90
SPRING UNLOADER SWIVEL STYLE
AF1920
$275.00
Third Hand Adapter for Bottom Clevis
AF1850
$12.00
SPRING UNLOADER
AF1910
$275.00
BILLET TIE
DOWN CLAMP
AF1810
$52.50
WHEEL KIT
AF1801
$59.75
SPRING SMASHER CANISTER CUP
AF1950
$98.75
CLEVIS ADAPTER KIT
MULTIPLE SIZES
$135.00
